TWO POST CLEAR FLOOR TUXEDO – TP9KAC-TUX
Roll over image to zoom in
$30,995.00
The Two Post Clear Floor Tuxedo TP9KAC-TUX is a practical lifting solution designed for automotive maintenance and repair facilities. Its clear floor design helps maximize workspace efficiency.
Product Highlights
- 9,000 lbs class lifting capacity
- Two post clear floor design
- Ideal for automotive service work
- Open floor workspace access
- Smooth lifting action
- Durable steel construction
- Reliable daily performance
TUXEDO – TP9KAC-TUX
9,000 lbs capacity
Specifications
| Lift Model | TP9KAC-TUX | |
| Capacity | 9,000 lbs. | |
| Height Overall | 142-11/16″ | |
| Width Overall w/ Power Unit | 141″ | |
| Max Lift Height | 72″ | |
| Width Between Columns | 110-3/8″ | |
| Min. Pad Height | 4″ | |
| Drive Thru Clearance | 93-11/16″ | |
| Lifting Speed | 50S | |
| Asymmetric / Symmetric | Asymmetric | |
| Clear Floor / Floor Plate | Clear Floor | |
| Short Arm Reach – min/max | 29″-41″ | |
| Long Arm Reach – min/max | 37″-57″ | |
| Narrow Bay Setting | NA | |
| Max Load Per Arm | 2,250 lbs. | |
| Ship Weight | 1,390 lbs | |
| Power | 220V – 20 AMP – 1PH |
